Adani Bifacial DCR 540 Watt

Name: Adani Bifacial DCR 540 Watt
Brand: Gigawatt Energy Private Limited
Price: 13770.0 INR
Availability: InStock

Price 13770.0 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

Adani Bifacial DCR 540 Watt Specification

Product Type
P-Type bifacial

Material
Monocrystalline Silicon

Number of Cells
144

Max Voltage
48.92 Volt (V)

Max System Voltage
540 Watt (W)

Panel Efficiency
21.00%

Size
540 watt

Dimension (L*W*H)
2266*1135*35 Millimeter (mm)

Weight
33.5 Kilograms (kg)

Color
Bifacial

Warranty
27 year

About Adani Bifacial DCR 540 Watt

Key Specifications

Here are typical / published specs for Adanis 540 W DCR modules (monofacial or bifacial) in their Eternal Shine / Elan Shine / ASB-M10-144-AAA series.

Parameter	Value / Range
Rated Power (STC)	540 Wp (also 535-545 W variants)
Number of Cells	144 half-cut mono PERC, MBB (multi-busbar) type cells; often 182 mm cell size in this range.
Voltage at Max Power (Vmp)	41.80 V
Current at Max Power (Imp)	12.93 A
Open-Circuit Voltage (Voc)	48.60-49.48 V depending on exact variant.
Short-Circuit Current (Isc)	13.60-13.80 A for many of the 540-545 W panels.
Efficiency	Around 21% or slightly above under STC for monofacial; for bifacial gains may increase depending on installation.
Dimensions	2266 1135 35 mm
Weight	28.8 kg (monofacial variants)
Mechanical Load	Wind / snow load ratings often 2400 Pa (rear) / 5400 Pa (front) etc.
Junction Box / Connectors	Typically IP67 or IP68; MC4 or compatible connectors; cable length 300 mm (varies).
Temperature Range	Operating range 40 C to +85 C (cell temperature) etc.
Warranty	Product warranty 10-12 years; performance warranty 25-30 years (for power output, e.g. 80-90% remaining at end of period)

What DCR Means

DCR = Domestic Content Requirement. Modules compliant with DCR are made using a certain amount of locally-sourced materials / manufacturing (i.e. Made in India requirements) in order to qualify for government solar subsidies / incentives. Adanis DCR modules meet those norms.
Often, there are Non-DCR variants (same or similar power, but made with some imported cell or component) too.

Pros / Strengths

High power output per panel (540 W) fewer panels needed for the same capacity saves space, structure, wiring.
Modern cell tech: half-cut cells, multi-busbar, good low-light performance, reduced losses from shading, etc.
Good efficiency (21%+) makes them competitive.
Strong mechanical durability (wind/snow load, durable frame, good junction box protection).
Solid warranties, with performance warranty over long term.
DCR compliance if project requires it (government subsidies, large commercial / rooftop etc).

Things to Check / Limitations

Size & weight: these modules are large/heavy (2.2 1.13 m, 2830 kg), so structural mounting, handling, transport need to be adequate.
Bifacial gain depends entirely on installation: ground reflectivity, spacing, tilt, height above ground etc; without rear light reflection gains will be small.
Temperature coefficient: in hot climates, performance drops; one should see what the % per C is for Pmax. Adanis spec shows 0.29%/C (see Eternal Shine datasheet) for some variants.
Voc at low temperature and total string voltage must be checked to avoid overvoltage issues.
Degradation over time, especially for bifacial (if used) and ensuring resistance to LID / LeTID / PID. Adani claims good resistance in many spec sheets.
